SAVVY® CargoTrac-ExR-M1

Power-Independent internal Primary Battery
Suitable for rail tank cars, dangerous goods transport, rail freight logistics, (tank) containers, construction machinery, assets of any kind
Approved for hazardous areas of zone 1 and 21
Guaranteed maintenance-free and self-sufficient operation for up to 15 years at temperatures down to -40 °C
Connection of external sensors via a 2.4GHz IEEE 802.15.4 (ZigBee) radio interface
Total cost savings through transport circulation and process optimization

PRODUCTIVITY THROUGH HIGH TECH

SAVVY® CargoTrac-ExR-M1 telematics device impresses with superior performance and a variety of interfaces for universal operation.

Drehgestell
Functions of SAVVY® CargoTrac-ExR-M1
Automated store floor data collection in rail, logistics and construction industries
Fleet management
Eco-drive driver feedback and evaluations
Refrigerated transport monitoring on rail cars, containers and trailers
Sensor monitoring
Traceability of damage events (identification of damage causers)
Increase in fleet utilization and (machine) availability
Total cost savings through process optimization
Control and monitoring of aggregates
Driver identification and order processing
Access monitoring for security transports
Anti-theft
Shock detection
Automatic stock control
Reduction of fuel consumption
Investment security thanks to modular solutions
Real-time monitoring in external voltage mode is possible without limiting service life

SAVVY® CargoTrac-ExR-M1 at a glance

SAFETY

Containers and machines equipped with SAVVY® CargoTrac-Ex are allowed to enter explosive areas of Zone 1 and Zone 21 according to Directive 2014/34/EU. In Zone 1 and Zone 21 there is occasionally a risk of explosive dust and gas mixtures, there is therefore a high requirement for the safety of the device. SAVVY® CargoTrac-Ex is certified for type of protection intrinsically safe Ex II 2 G Ex ib IIB T4 Gb and Ex II 2 D Ex ib IIIC T 135°C Db, thus meeting the high requirements.

PERFORMANCE

The high-tech telematics unit is ideally suited for the toughest requirements thanks to its compact and robust design. State-of-the-art RF technology enables continuous positioning (GPS, GLONASS) and communication even without external antennas is guaranteed at all times. Encrypted communication between the SAVVY® CargoTrac-Ex and the SAVVY® Synergy Portal is additionally secured by authentication and an integrity check.

WELL-FOUNDED INFORMATION

Industry-specific applications combined with dedicated interfaces make the device an efficient platform for processing vehicle data (CAN), sensor signals, input terminals, door and switch monitoring, data from cooling and heating units, etc.

BENEFITS

The use of a telematics-based Business Intelligence (BI) solution offers far-reaching optimization potential for logistics and transport processes. Starting with tracking and tracing applications, through situation-based damage and maintenance management, to sophisticated analyses for efficient procurement. This increases capacity utilization and reduces costs. SAVVY® CargoTrac-Ex opens up these advantages even under the stringent requirements of the chemical industry.

BATTERY-POWERED

Thanks to powerful lithium ion batteries combined with extremely energy-efficient technology, operating times of more than 15 years without maintenance are possible. This eliminates the need for a wired power supply.

ENCRYPTED

The SAVVY® CargoTrac-ExR-M1 communicates with the SAVVY® Synergy portal via an encrypted connection. In addition, authentication and data communication integrity checks ensure that your operational data is always secure.

PROMISE

High performance, ease of installation and far-reaching process optimizations ensure that the investment in SAVVY® solutions pays for itself in less than twelve months.

FURTHER ADVANTAGES

The SAVVY® CargoTrac-ExR-M1 is designed for quick installation and long-lasting, maintenance-free use in locomotives, temperature-controlled transports, tank containers, construction machinery or trailers. Thanks to modern RF technology, it requires no external antennas and, thanks to a powerful Li-ion battery, no wired power supply. Concealed installation, even inside, is possible without any problems.

  • OVERVIEW OF ALL TRANSPORTS IN REAL TIME
  • IDENTIFICATION OF THE PERSON WHO CAUSED THE DAMAGE
  • AUTOMATICALLY GENERATED QUALITY PROOFS
  • AUTOMATIC STOCK CONTROL
  • INCREASED FLEET UTILIZATION AND CARRIER AVAILABILITY
  • TOTAL COST SAVINGS THROUGH PROCESS OPTIMIZATION
  • INVESTMENT SECURITY THANKS TO MODULAR SOLUTIONS
